HBM QuantumX CX22B - QuantumX Module Connection

Connections and displays
16 A3169-8.0 HBM: public CX22B / CX22B-W
USB 3.0
START/STOP button
RS‐232‐C
Digital I/Os
Status LEDs
Monitor (DVI-D)
Ethernet
USB
Fig. 4.2 CX22B connections on the front
CFast
Supply voltage
DC 10  30V
Grounding
FireWire
Backplane con
nector strip
Fig. 4.3 Connections on the back for CX22 and CX22B‒W
