HBM QuantumX CX22B - Page 25

Connections and displays
CX22B / CX22B-W A3169-8.0 HBM: public 23
FunctionLED
4, 5, 6 Status of digital outputs
7 Module LED
8 Operating condition of the CFast memory card
(rear of module)
9 ERROR
10 RECORDING
1
2
3
4
5
6
7
8
10
9
Fig. 4.5 Position of the LEDs without WLAN
