HBM T40 - Page 30

30
T12
HBM
A24633.0en/de
View B (T40/ 500N@m and 1kN@m)
65
49
(24.25)24.75
12
17
corr. to stator ring and
meas. body flange
(depth of engagement)
Center of gravity
24.2
∅75
H6
∅75
g5
∅10.5
∅4.2 for axial locking
∅101.5
∅129
232
71
16
∅16∅16
j26j26
B
View B
