Electrical connection
22 A02590_04_E00_00 HBM: public TIM40
Anybus

‐interface module. The terminal assignments are printed on the front
panel.
Voltage supply
Shunt signal trigger
Transducer
connection T40
4321
Connection position of upper
spring‐loaded terminals
1234
Connection position of
lower spring-loaded
terminals
Analog outputs U/I
Frequency output
Ethernet connection RJ45
Slot for Anybus

‐module
Fig. 9.1 TIM40 inputs/outputs
