Specifications
TIM40 A02590_04_E00_00 HBM: public 51
16 Specifications
Type TIM40
Accuracy class 0.05
Energy supply
Nominal (rated) supply voltage V 18 ... 30
Nominal (rated) power consumption W < 20 W
Transducers that can be connected HBM's T40 Torque Flange
Inputs
Max. cable length m 50
Control signal input shunt
Input level “On” V > 2.5
Input level “Off” V < 1.5
Max. input voltage V 36
Max. input current at 24 V mA 24
Outputs
Frequency output
Nominal (rated) output signal at
10 kHz
60 kHz
240 kHz
kHz
kHz
kHz
10"5
60"30
1)
240"120
Max. modulation range at
10 kHz
60 kHz
240 kHz
kHz
kHz
kHz
4 ... 16
24 ... 96
96 ... 384
Output signal in case of error kHz 0
Level V 5 symmetrical
2)
Max. group delay (scaled, without filter) ms 200
Voltage output
Nominal (rated) output signal V -10.0 ... +10.0
Max. modulation range V -12.0 ... +12.0
