Specifications
52 A02590_04_E00_00 HBM: public TIM40
Output signal in case of error V 12.5 ... 15
Resolution mV 0.5
Measurement frequency range (-3 dB) Hz 0 ... 10000
Load resistance kW w 5
Long‐term drift over 48 h mV "5
Current output
Nominal (rated) output signal mA 12"8
Max. modulation range mA 3.4 ... 21.6
Output signal in case of error mA 23 up to 25
Measurement frequency range (-3 dB) Hz 0 ... 8000
Burden W v 500
Digital low‐pass filter (Bessel; can be
switched off)
Low‐pass filter TP 1 (-1 dB) Hz 1; 10; 100; 1000; 3000
Low‐pass filter TP 2 (-1 dB) Hz 1; 10; 100; 1000; 3000
1)
Factory settings
2)
Complementary signals per RS‐422, observe terminating resistors
Effect of temperature
per 10 K in the nomi
nal (rated) temperature
range
on the zero signal,
related to the nominal
(rated) sensitivity
Voltage output % 0.05
Current output % 0.05
Fieldbuses
Ethernet interface
Baud rate MBit/s 10 and 100
Connection RJ45
Protocol TCP/IP, UDP, DHCP
