Disclaimer: 3
rd
party and/or custom firmware providing extra features are not covered in this manual.
4K Integral 2 ā User Manual
[White Point]: Select the white point value to be used in the custom HDR metadata creation.
[Max Luminance]: Select the Max Luminance value to be used in the custom HDR metadata creation
(valid from 1 to 65535)
[MaxCLL]: Select the MaxCLL value to be used in the custom HDR metadata creation (valid from 1 to
65535)
[Min Luminance]: Select the Min Luminance value to be used in the custom HDR metadata creation
(valid from 1 to 65535)
[MaxFALL]: Select the MaxFALL value to be used in the custom HDR metadata creation (valid from 1 to
65535)
[Create IF]: Use the previous defined values to create the Custom HDR metadata.
[Send HDR]: Send the custom created HDR metadata. Please note that upon clicking, Enable Custom
HDR will get activated automatically, to stop the sending of the custom HDR metadata, uncheck Enable
Custom HDR. If Enable Custom HDR is activated then by pressing the Send HDR button, the metadata
injection does not stop, it just changes values, useful to avoid TV resync.
Note: There are two ways to reset the strings. Either hold the RESET button 10 seconds on Integral 2 or
go to the GUI "config" page and apply reset. After GUI reset close and reopen GUI. Then the fields are
populated with reset values.
Public API/DLL: We have created a set of DLL/API package for Integral 2 so anyone can interface their
Windows software with Integral 2 capabilities and build evaluation, testing, measurement, calibration
and content creation workflows system.
IR/RS232: Integral 2 can be fully controlled via IR or from any serial based computer such as Win, Max or
Linux using RS232 interface. Complete list of IR and RS232 commands are included as a text file for
convenience on all Firmware updater and GUI utility package.
