Ch. 8 V-BELT DRIVING SYSTEM
8-12
Service limit: 3.0 mm
Apply grease onto setting pins.
Install the spring into groove with pliers.
Install new clutch weight onto setting pin and then
push to the specified location. Apply with grease
onto setting pins.
Caution
Grease or lubricant will damage the clutch
weight and affect the block's connection capacity.
Install the spring plate and centrifugal clutch
To Next Page
