Ch. 1 GENERAL INFORMATION
1-7
When separating a connector, it locker has to Insert the terminal completely, unlocked it
first. Then, conduct the service Check if the terminal is covered by the boot. Do not let
boot open facing up.
Make sure the connector pins are not bent, extruded or loosen.
Do not pull the wires as removing a connector or wires. Hold the connector body.
Insert the connector completely. If there are two lockers on two connector sides, make
sure the lockers are locked in properly. Check if any wire loose.
Check if the connector is covered by both connector boots completely and secured
properly.
