Ch. 11 A.C.GENERATOR/STARTING CLUTCH
11-2
Precautions in Operation
General information
• Refertochapter18: The troubleshooting and inspection of alternator
• Refertochapter18: The service procedures and precaution items of starter motor
Specification
Torque
Flywheel nut 0.5-6.0kgf-m
Starting clutch hexagon bolt 1.0-1.4kgf-m with adhesive
8mm bolts 0.8-1.2kgf-m
12mm bolts 1.0-1.4kgf-m
Tools
Special tools
A.C.G. flywheel puller ：SYM-3110000-HMA
Universal holder: SYM-2210100
Item Standard value(mm) Limit(mm)
ID of starting clutch gear 27.026-27.045 27.050
OD of starting clutch gear 45.192-45.283 45.183
