Ch. 17 REAR BRAKE / WHEEL / SUSPENSION
17-10
Removal
Support the frame.
Loosen rear cushion under bolt nut, and remove
rear cushion under bolt.
Remove rear cushion upper bolt, and then
remove rear cushion.
Installation
Install rear cushion, and install rear cushion
upper bolt.
Install rear cushion under bolt, and install nut.
Tighten the rear cushion upper bolt and under nut
to the specified torque value.
Torque: 4.5 kg-m
