HERO GLAMOUR PROGRAMMED FI - Right Side View Parts Identification

14
RIGHT SIDE VIEW
(3) Kick starter pedal
(5) Oil level window
(1) Pillion foot rest
(4) Rider foot rest
(2) Battery compartment
(Inside) (8) Throttle body (Inside)
(10) Utility box
(9) Air suction valve
(6) Brake pedal
(7) Oil filler cap
(11) Caliper assembly
(12) Front brake disc
(13) Front turn signal lamp
(16) Exhaust muffler
(15) Visor
(14) Headlamp
13
15
*Accessories and features shown may not be part of standard fitment.
