49
Refer to the safety precautions on (page-29)
Check the front forks by locking the
front brake and pumping the front fork
up and down vigorously. The suspens-
ion action should be smooth and there
should be no oil leakage.
B
A
1
2
for adjusting stop lamp switch is as follows :
stop lamp switch at a point where the
stop lamp will glow just before the brake
HEADLAMP ADJUSTMENT
Headlamp is factory pre set. However in
case of adjustment required, please follow
the steps as given below :
1. Headlamp adjustment is done by the
headlamp adjusting bolt (1) located
below headlamp.
2. Park the motorcycle on level ground.
3. Adjust the headlamp beam vertically by
loosening the bolt & move the
headlamp unit forward & backward for
correct focus adjustment.
1
An improperly adjusted headlamp may
blind oncoming driver or it may fail to
light the road for a safe distance.
(1) Adjusting bolt
Stop lamp switch
