33
Refer to the safety precautions on (page-29)
• Do not remove the spark plug and test for
spark on the motorcycle by cranking the
engine as this could lead to fire or
explosion
2
Clean any dirt around the spark plug base.
4. Make sure that the spark plug gap is
0.8 - 0.9 mm using a wire-type feeler
gauge. if adjustment is necessary bend
the side electrode carefully. Make sure
the plug washer is in good condition.
6. Tighten a new spark-plug 1/2 turn with
a spark plug wrench to compress the
washer. If you are reusing a plug, it
should only take 1/8 - 1/4 turn after the
plug seats.
5. With the plug washer attached, thread
the spark plug in by hand to prevent
cross-threading.
(1) Noise suppressor cap (2) Spark plug
Disconnect the noise suppressor cap (1)
and remove the spark plug (2) with the
help of spark plug wrench provided in
the tool bag.
1
