(1) Fuel tank cap (2) Key hole cover
(3) Ignition key
17
Fuel tank capacity is 12 litres (minimum).
2. Do not overfill the tank. There should
be no fuel (4) in filler neck (5).
3. To lock - Position the cap back on the
opening with the arrow mark "D" on the
cap facing towards the front of the
motorcycle then press gently. The key
springs back to the normal position and
cap gets locked.
1. To unlock fuel tank cap (1) - Lift the
key hole cover (2), insert ignition key
(3) turn it clockwise and remove the
cap.
Do not park the motorcycle under direct
sunlight as it causes evaporation of petrol
due to heat and deterioration of paint gloss
due to ultra violet rays.
4
(4) Fuel
(5) Filler neck
5
3
2
1
