2 Hi beam indicator Light glows when headlamp is in Hi beam.
Sl. No. Description Function
Button when pressed switches display between
1 Mode / reset button
tripmeter and odometer. When tripmeter is
selected & button is long pressed it resets the
tripmeter to zero.
When the ignition switch is turned "ON" the
3
Programmed-FI
Programmed-FI Malfunction Indicator Lamp
glows for few seconds and then should go "OFF".
It indicates that Programmed FI system is OK.
If it "flashes", or remains "ON" there is an
abnormality in the Programmed FI, it is recommended
to reduce the speed and drive to the Authorised
Hero MotoCorp workshop for check-up.
headlamp.
5
8
6
2
4
1
7
9
10
PARTS FUNCTIONS
INSTRUMENTS AND INDICATORS
Malfunction Indicator Lamp
3
