45
Refer to the safety precautions on (page-29)
NOTE :
If proper adjustment cannot be obtained by
this method, see your Authorised Hero
MotoCorp workshop.
2
A
B
1
4
3
Replace the pads if worn out to the
bottom of the groove.
Always replace both the pads as a set.
Measure the distance brake pedal (1)
moves before the brake starts to take hold.
Free play (2) should be 20 - 30 mm.
Park the motorcycle on its main stand.
(2) Free play 20-30 mm
