NOTE :
If proper adjustment cannot be obtained by
this method, visit your Authorised Hero
MotoCorp workshop.
Apply the brake several times and check
for free wheel rotation when released.
2. Make free play adjustments by turning
the adjusting nut (3) at the front brake
arm (4).
Make sure the cut-out on the adjusting nut
(3) is seated on the brake arm pin (5) after
making final free play adjustment.
Refer to the safety precautions on (page-29)
Master cylinder / reservoir location : Right
handle bar.
3
5
CUT-OUT NOT SEATED PROPERLY
(3) Adjusting nut (5) Brake arm pin
3
5
CUT-OUT SEATED PROPERLY
x
Brake fluid recommended: DoT 3 or DoT 4
