The indicators are in the speedometer panel
above the headlamp. The functions are as
below.
Instruments and Indicators
1
2
678
13
Speedometer
Fuel gauge
High beam indicator
Side stand indicator
Neutral indicator
Turn signal indicators
Sl. No.
Description
2
3
Function
Indicates driving speed.
Odometer Shows accumulated distance travelled.
Gear shifting
Maximum operating speed in each gear.
1
7
6
4
8
5
Indicates approximate fuel quantity (page 14).
“ ”Light glows when headlamp is in Hi beam.
Light glows when the side stand is put down.
position. Light glows when vehicle is in neutral
Flashes when turn signal switch is operated.
9
i3s indicator
Indicator glows for 2 seconds and turns “OFF”
indicating that i3s system is functional.
10
Programmed-FI
malfunction indicator
lamp (MIL)
When the ignition switch is turned “ON” the programmed
FI malfunction indicator lamp (MIL) glows continuously
and then should go “OFF” once the engine is started. It
indicates that programmed FI system is OK. If it glows
continuously there is an abnormality in the programmed
FI system, it is recommended to reduce the speed and
drive to the Authorised Hero MotoCorp workshop for
check-up.
