1
A
B
2
(1) Stop lamp switch (2) Adjusting nut
(A) Advance (B) Retard
HEADLAMP ADJUSTMENT FOCUS
•
Turn the ignition switch to “ON” position
( ) and start the engine.
Headlamp is factory preset. However in case
of adjustment required, please follow the steps
as given below:
•
Park the vehicle on level ground.
•
Headlamp adjustment is done by the
headlamp adjusting screw (1) located below
headlamp.
•
Adjust the headlamp beam vertically by
rotating the screw. Rotate the screw
clockwise (A) for downward adjustment and
anticlockwise (B) for upward adjustment of
headlamp beam.
1
(1) Adjusting screw
(A) Clockwise (B) Anticlockwise
A
B
WARNING
!!
An improperly adjust headlamp may blind
oncoming rider/driver or it may fail to light the
road for a safe distance.
Follow these guidelines to protect your
vehicle’s catalytic converter.
CATALYTIC CONVERTER
This vehicle is equipped with the catalytic
converter in the muffler to meet the emission
norms. The catalytic converter contains
precious metals that serve as catalysts,
promoting chemical reactions to convert the
exhaust gasses without affecting the metals.
The catalytic converter acts on HC, CO and
NOx.
The catalytic converter must operate at a high
temperature for the chemical reactions to take
place. It can set on fire any combustible
material that come near it.
Park your vehicle away from high grasses, dry
leaves, or other flammable material.
A defective catalytic converter contributes to
air pollution and can impair your engine’s
performance.
53
