HERO SPLENDOR+ PROGRAMMED FI - Engine Oil Replacement

32
•
Fill the crankcase through the oil filler hole
with (approximately) of the 0.85 litre
recommended grade oil.
•
Reinstall the oil level dipstick with a new
O-ring.
•
Start the engine and allow it to idle for few
minutes.
•
Remove the tappet inspection cover. Slowly
accelerate and check the engine oil entry
into the cylinder head, engine oil will splash
out from the tappet inspection cover
opening.
•
After checking the oil circulation, install the
tappet inspection cover.
•
Stop the engine, let the engine oil settle
down and recheck the oil level.
•
Make sure that oil level is at the “UPPER”
level mark of the oil level dipstick with the
vehicle in an upright position and that there
are no oil leaks.
CAUTION
!!
•
Engine oil is a major factor affecting the
performance and service life of the engine.
Non-detergent, vegetable or castor based
racing oils are not recommended.
•
Running the engine with insufficient oil can
cause serious engine damage.
•
Running the engine with excessive oil can
cause spark plug fouling & loss in
performance.
(1) Drain bolt (2) Sealing washer
OIL FILTER SCREEN & CENTRIFUGAL
FILTER
• Remove the kick starter pedal (1), muffler
(2), disconnect the clutch cable (3) and
rider footrest (4). Remove the right
crankcase cover (5).
• Drain the engine oil thoroughly (page 31).
2
5
(1) Kick starter pedal (2) Muffler
(3) Clutch cable (4) Rider footrest
(5) Right crankcase cover
4
2
1
3
1
