16
(1) i3s switch
1
Starting & Warm up the engine:
Keep the i3s switch (1) to “OFF” position.
Turn the ignition key to “ON” ( ) position.
i3s (IDLE STOP START SYSTEM)
(2) i3s indicator
2
In this condition, the engine can be restarted
either with clutch lever, kick or electric start.
The i3s indicator (2) will glow on the
speedometer console for 2 seconds and turns
“OFF”. For the activation of i3s system, start
the engine and let it idle till the engine gets
Initial activation of the i3s system:
Keep the i3s switch (1) to “ON” position.
Turn the ignition key to “ON” position. The
i3s indicator (2) on the speedometer console
will glow for 2 seconds and turn “OFF”. Start
the vehicle (in neutral and clutch lever released
condition) with less than 2000 r/min and let
it idle till engine temperature reaches more
than 75°C. The engine will cut-off in 30
seconds. After the first stop start, every
subsequent stop will be in 5 seconds.
Driving with i3s switch in “ON” position:
While driving, if the engine is kept idling (while
waiting in a traf c signal), the engine will cut fi
off in 5 sec . (The vehicle should be inonds
stand still condition, with gear position neutral
at th n clutch less a 2000 r/min with
lever/throttle is in released position and
engine is warmed up The i3s indicator will ).
be continuously blinking in the speedometer
indicating that vehicle stopped in i3s
condition. By pressing the clutch lever, the
engine will start again and gear can be
engaged to move the vehicle.
warmed up or temperature reaches more than
75°C.
