HERO SPLENDOR+ PROGRAMMED FI - Engine Oil Level Inspection

3. Lower level mark
1. Oil level dipstick 2. Upper level mark
2
UPPER
LOWER
31
Manufactured by:
Check engine oil level each day before
operating the vehicle.
GRADE: SAE 10W 30 SL Grade
•
Bharat Petroleum Corporation Limited.
BRAND: Hero 4T plus
The oil level dipstick (1) is on the right
crankcase cover for measuring oil level. Oil
level must be maintained between the upper
(2) and lower (3) level marks on the oil level
dipstick.
Engine oil level inspection/Top up
process
ENGINE OIL
OIL CAPACITY: 1 litres
•
Tide Water Oil Co. (India) Ltd.
Use hero genuine engine oil or recommended
grade oil.
•
Savita Oil Technologies Limited.
(JASO MA2).
Do top up if oil level reaches towards the lower
level mark or every 3000 km whichever is
earlier.
•
top the engine and wait for 2-3 minutes.S
•
Turn the i3s switch to “OFF” position.
•
Park the vehicle on its main stand.
•
Remove the oil level dipstick and check the
oil level.
•
Start the engine & let it idle for 3-5
minutes.
•
If required, add the specified oil up to the
upper level mark. Do not overfill.
•
Quantity of oil to be filled is 0.85 litre
(approx.) during oil change when right
crankcase cover is not removed.
•
Reinstall the oil level dipstick and check for
oil leaks.
•
Remove the oil level dipstick, wipe it clean
and insert without screwing it in.
The engine will stall if the i3s switch is in
“ON” position during warmup.
NOTE
Engine oil replacement process/
Oil circulation inspection
Drain engine oil with the engine warm and the
vehicle on its main stand.
•
To drain the oil, remove the oil level dipstick
and drain bolt (1) with sealing washer (2).
•
After the oil has completely drained,
reinstall the drain bolt with a new sealing
washer.
1
3
