HERO SPLENDOR+ PROGRAMMED FI - Vehicle Views; Top View Components

(1) Turn signal indicator
(4) Turn signal lamp switch
(2) Side stand indicator
(3) Horn switch
(5) Clutch lever
(6) Rear view mirror
(10) i3s indicator
(9) Speedometer
(11) Neutral indicator
(8) Odometer
(7) Headlamp dimmer switch
(14) High beam indicator
(15) i3s switch
(21) Leg guard
(13) Fuel gauge
(12) Programmed FI malfunction indicator
lamp (MIL)
(16) Front brake lever
(17) Throttle grip
(18) Electric starter switch
(19) Ignition switch with steering lock
(20) Fuel tank lid
TOP VIEW
3
5
6
17
16
21
18
2
VEHICLE VIEWS
4
1
2
10
11 13
19
*Accessories and features shown may not be part of standard fitment.
8 9
14 15
12
20
7
