HERO SPLENDOR+ PROGRAMMED FI - Right Side View Components

(7) Oil level dipstick
(10) Headlamp
(6) Rear brake pedal
(8) Utility box
(9) Front suspension
(12) Fuel tank
(11) Front visor
(13) Seat
(14) Rear shock absorber
(15) Exhaust muffler
RIGHT SIDE VIEW
(2) Battery compartment (Inside)
(1) Pillion footrest
(3) Kick starter pedal
(4) Rider footrest
(5) Starter motor
10
11
2
3
*Accessories and features shown may not be part of standard fitment.
1
4
5
9
8
9
12
13
15
4
7
14
