HERO SPLENDOR+ - Page 6

(2) Gear shift pedal
(5) Side stand
(3) Main stand
(4) Side stand switch
(6) Pillion foot rest
(1) Carburetor
(8) Saree guard
(7) Women pillion step
(10) Rear turn signal lamp
(11) Tail/Stop lamp
(9) Reflex reflector
(13) Left side cover
(12) Rear carrier
(15) Front turn signal lamp
(16) Front reflex reflector
(14) Fuel valve
11
13
14
LEFT SIDE VIEW
2
5
6
*Accessories and features shown may not be part of standard fitment.
