HERO SPLENDOR+ - Page 7

4
(6) Oil level dipstick
(7) Rear brake pedal
(8) Utility box
(10) Headlamp
(9) Front suspension
(11) Front visor
(12) Fuel tank
(13) Seat
(15) Exhaust muffler
(14) Rear shock absorber
RIGHT SIDE VIEW
(1) Pillion foot rest
(3) Kick starter pedal
(4) Rider foot rest
(2) Battery compartment (Inside)
(5) Starter motor
9
10
11
15
2
3
4
7
8
*Accessories and features shown may not be part of standard fitment.
5
9
1
12
13
14
