18
SIDE STAND INDICATOR/SWITCH
For the safety of the customer a side stand
indicator (1) is provided.
A side stand switch (2) is provided in the side
stand, when the vehicle is parked on side stand
(Ignition switch “ON”), the switch enables the
side stand indicator lamp to glow on the
speedometer panel.
(1) Side stand indicator
2
(2) Side stand switch
FUEL TANK
Fuel tank capacity is 12 litres (Be sure to fill
the fuel tank when fuel gauge needle enters
red band).
• To remove the fuel tank cap (1), open the key
hole cover (2) and insert the ignition key (3)
turn it clockwise and remove the cap.
2
(1) Fuel tank cap (2) Key hole cover
(3) Ignition key
(4) Filler neck (5) Fuel
5
4
1
3
1
