*Accessories and features shown may not be part of standard fitment.
(1) High beam indicator
(2) USB charger (Optional)
(3) Dimmer switch
(7) Passing switch
(9) Neutral indicator
(8) Rear view mirror
(10) Programmed FI malfunction indicator
lamp (MIL)
(11) Side stand indicator
(5) Turn signal switch
(6) Clutch lever
(4) Horn switch
(13) i3s indicator
(14) Speedometer
(15) Odometer
(16) Fuel indicator
(17) Front brake master cylinder/Reservoir
(19) Front brake lever
(20) Throttle grip
(21) Electric starter switch
(22) Ignition switch with steering lock
(23) Fuel tank cap
(18) i3s switch
(12) Turn signal indicator
TOP VIEW
VEHICLE VIEWS
15
16
11
14
12
10
9
13
17 18
1
2
6
7
8
4
5
3
19
22
20
21
23
