HERO SUPER SPLENDOR PROGRAMMED FI - ENGINE OIL; Engine Oil Level Inspection and Top-Up

32
(1) Oil level dipstick (2) Upper level mark
(3) Lower level mark
UPPER
LOWER
1
(4) Engine oil check bolt
•
Remove the oil level dipstick, wipe it clean
and insert without screwing it in.
•
Remove the oil level dipstick and check the
oil level.
•
After checking the oil circulation, tighten the
engine oil check bolt.
•
If required, add the specified oil up to the
upper level mark. Do not overfill.
•
Stop the engine and wait for 2-3 minutes.
GRADE: SAE 10W 30 SL Grade
ENGINE OIL
Use hero genuine engine oil or recommended
grade oil.
BRAND: Hero 4T plus
•
Tide Water Oil Co. (India) Ltd.
•
Savita Oil Technologies Limited.
OIL CAPACITY: 0.95 litre (disassembly)
: 0.75 litre (at oil change)
Engine oil level inspection/Top up
process
Manufactured by:
(JASO MA2).
Check engine oil level each day before
operating the vehicle. The oil level dipstick (1)
is on the right crankcase cover for measuring
oil level. Oil level must be maintained between
the upper (2) and lower (3) level marks on
the oil level dipstick.
•
Bharat Petroleum Corporation Limited.
•
Park the vehicle on its main stand.
•
Turn the i3s switch to “OFF” position.
Do top up if oil level reaches towards the lower
level mark or every 3000 km whichever is
earlier.
•
Start the engine & let it idle for 3-5
minutes.
•
Slightly loosen the engine oil check bolt (4)
and check the engine oil entry into the
cylinder head.
2
3
4
