• Reinstall the dowel pins, new gasket,
• Fill the crankcase with clean engine oil as
per specification.
• Install the side stand switch screw.
crankcase cover, kick starter pedal, rider
footrest assembly with side stand, exhaust
muffler and clutch cable.
• Adjust the clutch cable free play, if required
(page 39).
•
Reinstall the oil filter screen with the sharp
edged side facing inwards.
Ensure to replace gasket with new one once
removed.
NOTE
•
Remove the oil filter screen (9) and wash it
in clean non flammable or high flash point
solvent (kerosene).
•
Remove the gasket (7) and dowel pins (8).
(7) Gasket (8) Dowel pins
(9) Oil filter screen
9
6
5
1
(2) Clutch cable (3) Exhaust muffler
(1) Side stand switch screw
(5) Kick starter pedal (6) Right crankcase cover
(4) Rider footrest assembly with side stand
Air cleaner element inspection
AIR CLEANER
• (page 19).Remove the seat
•
Remove the air cleaner cover screws ( ) 1
and the cover ( ).2
The air cleaner is viscous paper pleated type
filter which has enhances filtering efficiency.
The air cleaner replacedshould be at regular
intervals When riding in dusty (page 28).
areas, more frequent may be replacement
necessary.
3
8
7
4
2
