HERO SUPER SPLENDOR PROGRAMMED FI - Left Side View

3
*Accessories and features shown may not be part of standard fitment.
LEFT SIDE VIEW
1
2
3
4
6
7
8
10
13
12
(6) Side stand
(1) Leg guard (Optional)
(4) Main stand
(2) Rider footrest
(3) Gear shift pedal
(5) Left side cover
(7) Pillion footrest
(13) Tail/Stop lamp
(12) Rear reflex reflector
(10) Rear fender
(8) Saree guard with
women pillion step
(11) Rear turn signal lamp
(9) Seat lock
(18) Front suspension
(16) Battery (inside)
(19) Front fender
(20) Front reflex reflector
(17) Side stand switch
(14) Rear grip
(15) Helmet holder (inside)
