HERO SUPER SPLENDOR PROGRAMMED FI - Right Side View

4
#
(8) Caliper assembly
#
(9) Front brake disc
(11) Headlamp
(7) Kick starter pedal
(12) Front visor
(10) Front turn signal lamp
(14) ECU (inside)
(15) Seat
(16) Rear shock absorber
(17) Exhaust muffler
(13) Throttle body
(2) Brake fluid reservoir
#
(3) Right side cover
(5) Brake pedal
(1) CBS Actuator (inside)
#
(4) Starter motor
(6) Oil level dipstick
11
12
*Accessories and features shown may not be part of standard fitment.
4
17
RIGHT SIDE VIEW
31
# Disc Variant
2 4 7 8
9
15 14 13
65
10
16
