HERO SUPER SPLENDOR PROGRAMMED FI - Brake Wear Indicators

47
(3) Reference mark (4) Brake panel
(1) Arrow (2) Brake arm
Rear brake wear indication
3
2
4
(1) Arrow (2) Brake arm
(3) Reference mark (4) Brake panel
1
2
(f) Brake wear indicators
When the brake is applied, an arrow (1), fixed
to the brake arm (2), moves towards a
reference mark (3) on the brake panel (4).
(3) Adjusting nut (4) Brake joint pin
A
B
(A) Decrease free play (CW)
(B) Increase free play (ACW)
(3) Adjusting nut (4) Brake joint pin
ü
X
(A) Cut-out not seated (B) Cut-out seated
3
44
3
NOTE
If proper adjustment cannot be obtained by
this method, visit your Authorised Hero
MotoCorp workshop.
If the arrow aligns with the reference mark on
full application of the brake, the brake shoes
must be replaced.
3
4
3
1 4
Front brake wear indication
( )Drum variant
