56
2
(1) Left side cover screws (2) Side cover
(3) Tab/slot (4) Lugs/grommets
1
3
• Remove the battery clamp bolt (9) and the
battery clamp (10).
• Remove the fuel tank left side cover bolt (5)
and remove the cover (6) by releasing the
tab (7) from the slot (8).
• Disconnect the negative (-)ve terminal lead
(11) from the battery first, then disconnect
the positive (+)ve terminal lead (12).
• Pullout the battery (13) from the battery
box.
(9) Battery clamp bolt (10) Battery clamp
(11) (-)ve terminal (12) (+)ve terminal
(13) Battery
5
6
8
7
(5) Fuel tank left side cover bolt
(6) Fuel tank left side cover (7) Tab (8) Slot
910
11
12
13
•
Remove the left side cover screws (1) and
remove the side cover (2) by releasing the
tabs from the slots (3) and lugs from the
grommets (4).
•
(pages 21)Remove the seat .
•
FF” ( ). Make sure the ignition switch is “O
Battery removal
•
Ensure the battery leads are properly
connected to the battery terminals during
installation.
4
