In the top right hand corner of the program screen the row number, sequence or column number and the
cursor position number are displayed, “C1-1”.
In example above the cursor is positioned on row 1 “R001”, in the first sequence or column of zones “C1”, on
the first editable field in the row. “-1”. Program 1 has been set up so that zone 01 will run for 30 seconds,
followed by zone 03 to run for 1 minute.
Moving the cursor with arrows keys changes the row number, sequence or column number and the cursor
position number displayed.
If the option to allow parallel running of zones within a program has been set then or column number will
change to “C2.
Zone 02 has been set to run for 1 minute in parallel with zone 1 and zone 04 to run for 2 minutes in parallel
with zone 03.
When program 1 is run the sequence of zones will be as follows:
Zone 01 and zone 02 will start together.
Zone 01 will run for 30 seconds, zone 02 will run for 1 minute.
Once zone 02 has completed its 1 minute run time, then zone 03 and zone 04 will start.
Row numbers are used to set a common value for a set of zones. - See section 12 “Short Cuts”.
Press the MENU key to return to the Main Menu.
