Select “FLOW VOLUME” from the Main Menu. The Flow Menu will be displayed.
Select “DISPLAY FLOW” from the Flow Menu.
If a program is running then the real-time flow will be displayed.
The daily volume of water will be displayed. This volume is reset to zero at midnight, or when manually reset
from the “CLEAR VOLDAILY “option on the Flow Menu.
The total volume measured through the flow meter is also displayed. The volume will increase until this is
manually reset from the “CLEAR VOLTOTAL “option on the Flow Menu.
The HOLD OFF field displays a countdown in seconds of the delay before the measuring of a flow through a
zone starts.
The expected low and high flow volumes for each zone can be specified on the “ZONE CONFIG” screen.
The “HIGH LIMIT” and “LOW LIMIT” fields will display the expected flow limits according to the zone running
at that moment in time. If zones are running in parallel, then the accumulative limits for the zones will be
displayed.
29. Flow Test Enabled
Setting this option to 001 to will result in a text message being sent if the measured flow volume is not within
a zone’s expected flow range. The expected flow volume for each zone can be specified on the “ZONE
CONFIG” screen
30. Advance Lo Flow
If this option is set to 001 then an irrigation program will advance to the next zone in the program sequence
should a low flow volume fault be detected.
31. Advance Hi Flow
If this option is set to 001 then an irrigation program will advance to the next zone in the program sequence
should a high flow volume fault be detected.
32. Max Flow Faults
FLOW VOULME 1
FLOW 000.0 LPM
VOLDAILY 00 LITRES
VOLTOTAL 00 LITRES
HOLD OFF 00
HIGH LIMIT 000.0 LPM
LOW LIMIT 000.0 LPM
