21. Parallel Manual Starts
Set this option from 001 to 004 to specify the maximum number of zones that can be manually started when
a program is running.
28. Number of Flow Meters
A standard controller can have one flow meter connected Up to an additional 9 flow meters can be added
with the addition of expansion cards. A single flow meter is connected across the “+V D G” and “+V F G”
terminals.
Set this option to 001 if a single flow meter is connected. “FLOW METER” will be displayed in the Option
Menu and “FLOW VOLUME” will be displayed in the Main Menu.
Select “FLOW METER” from the Option Menu.
With the cursor on the METER TYPE field press the OK/SELECT button to set the meter type according to
the type of flow meter connected.
VOL 1 L – Pulse meter 1 litre/Gallon
VOL 10 L – Pulse meter 10 litres/Gallon
VOL 100 L – Pulse meter 100 litres/Gallon
VOL 1000 L – Pulse meter 1000 litres/Gallon
ROTOR – Paddle wheel meter
A single flow meter is connected to 2W1 as standard. This field needs to be changed if additional cards have
been added.
Set the K-FACTOR if a pulse meter has been connected.
If “FLOW TESTING” has been active – see option 29, then a “DELAY BEFORE TEST” time in seconds can
be specified, before the measuring of the flow through a zone starts.
The FLOW LEAK field can be set to a volume of water that can be measured before a flow fault text alert
message is sent.
Setting this option to 001 will also display “FLOW VOLUME” in the Main Menu.
METER 1
METER TYPE VOL 1 L
METER CONNECTED TO 2W1
K-FACTOR 00:00
DELAY BEFORE TEST 000 SECS
LEAK FLOW 0000 LPM
To Next Page
