Set Up and Edit Zone Information
a. Zone Configuration
Decoder Serial Numbers and zone properties need to be entered for each irrigation zone.
Select “ZONE INFO” from the Main Menu and the Zone Menu will be displayed.
Select “ZONE CONFIG” from the Zone Menu.
The decoder serial number is shown on the side of each decoder. Any decoder serial number can be
assigned to any zone. For example, if you want a decoder with serial number 012345 to be zone 1, enter
012345 in the serial number field for zone one on this screen.
Your controller can operate up to 100 zones on one card “2W1”. An additional card, “2W2”, has been added
to the controller to support more than 100 zones. If your controller has more than one card then the card
number associated with each zone should be entered.
If there is a flow meter connected to your controller, then the expected maximum and minimum flow rate in
litres/seconds can be entered for each zone.
Likewise, if more than one water meter is connected to your controller, then the meter associated with each
zone should be entered.
A delay in seconds between a zone stopping and the next one in the sequence starting can be set.
Zones can also be assigned to groups. Zones properties, such as adjusting zone run times by a given
percentage, can be applied to a group of zones.
b. Change Zone Name
Zone names can also be changed to a 10 character name of your choice.
To change a zone name, remain on the Zone Config screen.
Position the cursor over the zone number and press the ”OK/SELECT” key.
Use the on screen keypad to enter the name of your choice.
Press the MENU key to return to the Zone Config screen.
Press the MENU key to return to the Zone Menu.
ZONE CONFIG
ZN SN CD HIFL LOFL WM DELAY G
1 012345 2W1 0600 0000 0 0:00 1
2 000000 2W1 0600 0000 0 0:00 1
3 000000 2W1 0600 0000 0 0:00 1
4 000000 2W1 0600 0000 0 0:00 1
5 000000 2W1 0600 0000 0 0:00 1
To Next Page
