DTC4500e Card Printer User Guide, PLT-01669, 1.0
Description Supplies (pictured)
Four (4) Printhead Cleaning Swabs are
pre-moistened with 99.99% isopropyl
alcohol for cleaning your printer’s
printhead.
Three (3) Alcohol Cards are premoistened
with 99.99% isopropyl
alcohol for cleaning your printer’s
platen, and card feed rollers.
Ten (10) Cleaning Cards are provided
with adhesive backing for cleaning your
printer’s platen and card feed rollers.
4.1.3.3 Printhead Cleaning
Step Procedure
1
Caution: Turn Off the printer and unplug the power cord from the
printer.
2
Remove the ribbon cartridge.
3
Open the Printhead Cleaning Swabs. Break it to moisten the tip.
4 Swab the tip back and forth across the top of the printhead. Allow to dry thoroughly before
sending a print job.
