5.10 Network Settings Tab
The Network Settings tab provides the ability to adjust network settings for a specific installation.
Field Description
IP Host Name Host name for use with multicast DNS (local) and DHCP Client. Default U90.
Connection Type
Enable the DHCP Client to receive an IP address from an external DHCP Server
for the U90, or manually set the Static IP.
IP Address IP address of the reader, used if DHCP is not enabled.
TFTP Enabled Enables/disables the TFTP server for firmware and configuration.
IP Address Displays the current IP address.
Net Mask Net Mask of the reader, used if DHCP is not enabled.
Gateway Default Gateway for the reader, used if the DHCP is not enabled.
Connection Displays the current connection type.
IP Address IP address of the reader, used if DHCP is not enabled.
Net Mask Displays the current Net Mask.
Gateway Displays the current Gateway address.
Change User Password Enter new password for the device.
