Page 4
PLT-01952, Version: A.2 June 2015
2.1.1.3 Car Heights
There are many possible car heights that need to be taken into consideration:
2.1.1.4 Mounting Type
The reader will need to be installed at a optimal hight and angle to read the cards properly.
• Wall
• Post
2.1.1.5 Interference (objects/radio/lights)
An obstruction free area is required for optimal performance.
2.1.2 Tools Needed
• Ladder
• Ethernet cable
• Drill
• Scissors
• Laptop with Ethernet connector
• Ethernet cable (to connect from the laptop to the reader)
7 Ft.
20 Ft. 0 - 6 Ft.
GatePole
Reader
Aim Point
