A-4 DMX Protocols Technobeam
®
User Manual
Position 4 40 - 47 16 - 18 28h - 2Fh
Position 5 48 - 55 19 - 21 30h - 37h
Position 6 56 - 63 22 - 24 38h - 3Fh
Position 7 64 - 71 25 - 27 40h - 47h
Position 8 72 - 79 28 - 30 48h - 4Fh
Position 9 80 - 87 31 - 34 50h - 57h
Position 10 88 - 95 35 - 37 58h - 5Fh
Position 11 96 - 103 38 - 40 60h - 67h
Position 12 104 - 111 41 - 43 68h - 6Fh
Position 13 112 - 127 44 - 49 70h - 7Fh
Half color 1 and 2 128 - 143 50 - 56 80h - 8Fh
Half color 2 and 3 144 - 151 57 - 59 90h - 97h
Half color 3 and 4 152 - 159 60 - 62 98h - 9Fh
Half color 4 and 5 160 - 167 63 - 65 A0h - A7h
Half color 5 and 6 168 - 175 66 - 68 A8h - AFh
Half color 6 and 7 176 - 183 69 - 71 B0h - B7h
Half color 7 and 8 184 - 191 72 - 74 B8h - BFh
Half color 8 and 9 192 - 199 75 - 78 C0h - C7h
Half color 9 and 10 200 - 207 79 - 81 C8h - CFh
Half color 10 and 11 208 - 215 82 - 84 D0h - D7h
Half color 11 and 12 216 - 223 85 - 87 D8h - DFh
Half color 12 and 13 224 - 231 88 - 90 E0h - E7h
Half color 13 and 1 232 - 247 91 - 96 E8h - F7h
Color wheel continuous forward/
reverse spin (use with ch. 5 (F)
or 3 (R))
No spin 0 - 3 0 - 1 00h - 03h
Slowest spin to fastest
spin
4 - 255 2 - 100 04h - FFh
Color wheel continuous
variation (wheel position is 360 *
(channel dec. value / 255)
Use with ch. 5 (F) or 3 (R)
Centered on position 1
(open)
0
255
0
100
00h
FFh
Centered on position 2 19 7 13h
Centered on position 3 39 15 27h
Centered on position 4 58 23 3Ah
Centered on position 5 78 31 4Eh
Centered on position 6 98 38 62h
Centered on position 7 117 46 75h
Centered on position 8 137 54 89h
Centered on position 9 156 61 9Ch
Table A-1. Technobeam DMX Protocol
Ch. (F) Ch. (R) Construct Parameter
Value
(dec.)
Value
(%)
Value
(hex)
