A-12 DMX Protocols Technobeam
®
User Manual
MSpeed Movement Times
Use Table A-3 to determine the MSpeed (motor/mirror) movement times for
Technobeam, Technopro or Technoray in seconds.
An MSpeed (motor/mirror speed) change occurs smoothly over the entire
MSpeed time value. For example, if you choose a numerical DMX value of 202
for an MSpeed color change from position 2 to position 4, that means the color
wheel changes gradually to position 4 over 11.41 seconds.
Note
The values displayed in the “Value (%)” , “Value (hex)” and “Value
(num)” columns may vary slightly depending on your controller’s
rounding conventions.
17
(cont.)
Macro/LAD™
(cont.)
Macro 9 40-43 16-17 28-2B
Macro 10 44-47 17-18 2C-2F
Macro 11 48-51 19-20 30-33
Macro 12 52-55 20-22 34-37
Macro 13 56-59 22-23 38-3B
Macro 14 60-63 24-25 3C-3F
Macro 15 64-67 25-26 40-43
Macro 16 68-71 27-28 44-47
Macro 17 72-75 28-29 48-4B
Macro 18 76-79 30-31 4C-4F
Macro 19 80-83 31-33 50-53
Macro 20 84-87 32-34 54-57
Macro 21 88-91 34-36 58-5B
Macro 22 92-95 36-37 5C-5F
Macro 23 96-99 38-39 60-63
Macro 24 100-103 39-40 64-67
Macro 25 104-107 41-42 68-6B
Macro 26 108-111 42-44 6C-6F
Macro 27 112-115 44-45 70-73
Macro 28 116-119 46-47 74-77
LAD Off 120-127 47-50 78-7F
LAD Modulate Slowest 128 50 80
LAD Modulate Fastest 247 97 F7
LAD On Continuously 248-255 97-100 F8-FF
18 Control
Note: Shutter
(channel 14) must
be set to “0” to
access the control
functions.
Safe 0-7 0-3 00-07
Display Off 24-26 9-10 18-1A
Display Dim 32-34 12-13 20-22
Display Bright 40-42 16-17 28-2A
Home 64-66 25-26 40-42
Lamp On 80-82 31-32 50-52
Lamp Off 96-98 37-38 60-62
Shutdown 128-130 50-51 80-82
Table A-2. Technobeam-i DMX Protocol
Ch. Construct Parameter
Value
(dec.)
Value
(%)
Value
(hex)
