1-2 Specifications Technobeam
®
User Manual
Specifications
Model Numbers
Model:
Technobeam
Manufacturer:
Lightwave Research
®
Distributor:
High End Systems, Inc.
2217 W. Braker Lane
Austin, Texas, 78758 USA
Dimensions (with yoke and handles)
in: 34 L x 13 H x 16 W
cm: 86 L x 33 H x 41 W
Note
The height of the fixture without the yoke is 9.6 in. (24
cm).
Weight (including yoke)
41 lbs (19 kg)
Electrical Specifications
•
Voltages:
100/120/230 V; 50 Hz; 3.75/3.13/1.6 A
100/120/208 V; 60 Hz; 3.75/3.13/1.8 A
•
Rated power:
375 W
•
Power factor, 120V, 60 Hz:
0.96
•
Power factor, 230V, 50 Hz:
0.90
•Fuses:
•
F1
—125V, 4.0A, Fast Blow Only (5mm x 20mm)
•
F2
—250V, 2.5A, Fast Blow Only (5mm x 20mm)
•
F3
—250V, 6.3A, Slow Blow Only (5mm x 20mm)
Class I equipment - This equipment must be earthed.
Technobeam Laser Aiming
Device™ (LAD
™
)
The specifications below apply
only
to Technobeam fixtures that have
the Laser Aiming Device (LAD) installed.
• Class 3a laser product
• Beam divergence angle: 0.2mRad to 0.3mRad
TM
