User Manual DMX Protocols A-15
Macro Channel Assignments
Table A-4 below lists the macro channel assignments.
This information is
preliminary and subject to change
. A
macro
is predefined set of constructs
you can use when programming a scene. You do not have to use macros in
your scene, but using them can save you programming time.
Use DMX channel number 17 to access Technobeam macros.
Table A-4. Macro DMX Channel Assignments
Macro Number Value (dec.) Value (%) Value (hex)
off 0 - 7
120 - 255
0 - 3
47 - 100
00h - 07h
78h - FFh
1 8 - 11 4 08h - 0Bh
2 12 - 15 5 0Ch - 0Fh
3 16 - 19 6 - 7 10h - 13h
4 20 - 23 8 - 9 14h - 17h
5 24 - 27 10 18h - 1Bh
6 28 - 31 11 - 12 1Ch - 1Fh
7 32 - 35 13 20h - 23h
8 36 - 39 14 - 15 24h - 27h
9 40 - 43 16 28h - 2Bh
10 44 - 47 17 - 18 2Ch - 2Fh
11 48 - 51 19 - 20 30h - 33h
12 52 - 55 21 34h - 37h
13 56 - 59 22 - 23 38h - 3Bh
14 60 - 63 24 3Ch - 3Fh
15 64 - 67 25 - 26 40h - 43h
16 68 - 71 27 44h - 47h
17 72 - 75 28 - 29 48h - 4Bh
18 76 - 79 30 4Ch - 4Fh
19 80 - 83 31 - 32 50h - 53h
20 84 - 87 33 - 34 54h - 57h
21 88 - 91 35 58h - 5Bh
22 92 - 95 36 - 37 5Ch - 5Fh
23 96 - 99 38 60h - 63h
24 100 - 103 39 - 40 64h - 67h
25 104 - 107 41 68h - 6Bh
26 108 - 111 42 - 43 6Ch - 6Fh
27 112 - 115 44 - 45 70h - 73h
28 116 - 119 46 74h - 77h
