A-8 DMX Protocols Technobeam
®
User Manual
Percentage (%) column may vary slightly depending on your controller’s rounding
convention.
Table A-2. Technobeam-i DMX Protocol
Ch. Construct Parameter
Value
(dec.)
Value
(%)
Value
(hex)
1 Pan (mirror)
position
Coarse adjustment (8-bit) 0 - 255 0 - 100 00 - FF
2 Pan (mirror)
position
Fine adjustment (8-bit) 0 - 255 0 - 100 00 - FF
3 Tilt (mirror) position Coarse adjustment (8-bit) 0 - 255 0 - 100 00 - FF
4 Tilt (mirror) position Fine adjustment (8-bit) 0 - 255 0 - 100 00 - FF
5 Color Function
Full Speed Control
Indexed 0-15 0-6 00-0F
Forward Spin 16-31 7-12 10-1F
Reverse Spin 32-47 13-18 20-2F
Continuous 48-63 19-25 30-3F
Slow Scan 64-79 26-31 40-4F
Fast Scan 80-95 32-37 50-5F
Random 96-111 38-44 60-6F
Blink 112-127 45-50 70-7F
MSpeed Control
Indexed 128-143 51-56 80-8F
Forward Spin 144-159 57-62 90-9F
Reverse Spin 160-175 63-69 A0-AF
Continuous 176-191 70-75 B0-BF
Slow Scan 192-207 76-81 C0-CF
Fast Scan 208-223 82-88 D0-DF
Random 224-239 89-94 E0-EF
Blink 240-255 95-100 F0-FF
6 Color Wheel
Position
Indexed and Blink Modes
Color 1 0-23 0-9 00-17
Color 2 24-31 10-12 18-1F
Color 3 32-39 13-15 20-27
Color 4 40-47 16-18 28-2F
Color 5 48-55 19-21 30-37
Color 6 56-63 22-25 38-3F
Color 7 64-71 26-28 40-47
Color 8 72-79 29-31 48-4F
Color 9 80-87 32-34 50-57
Color 10 88-95 35-37 58-5F
Color 11 96-103 38-40 60-67
Color 12 104-111 41-44 68-6F
Color 13 112-127 45-50 70-7F
Colors 1 and 2 128-143 51-56 80-8F
Colors 2 and 3 144-151 57-60 90-97
Colors 3 and 4 152-159 61-62 98-9F
Colors 4 and 5 160-167 63-66 A0-A7
Colors 5 and 6 168-175 67-69 A8-AF
Colors 6 and 7 176-183 70-72 B0-B7
Colors 7 and 8 184-191 73-75 B8-BF
Colors 8 and 9 192-199 76-78 C0-C7
Colors 9 and 10 200-207 79-81 C8-CF
To Next Page
