Technobeam
®
User Manual DMX Protocols A-9
6
(cont.)
Color Wheel
Position (cont.)
Colors 10 and 11 208-215 82-84 D0-D7
Colors 11 and 12 216-223 85-88 D8-DF
Colors 12 and 13 224-231 89-91 E0-E7
Colors 13 and 1 232-247 92-97 E8-F7
Color 1 248-255 98-100 F8-FF
Continuously Variable Forward Spin Mode
Spin Stop 0-3 0-1 00-03
Spin Forward Slowest 4 2 04
Spin Forward Fastest 255 100 FF
Continuously Variable Reverse Spin Mode
Spin Stop 0-3 0-1 00-03
Spin Reverse Slowest 4 2 04
Spin Reverse Fastest 255 100 FF
Continuously Variable Mode
Color 1 (open) 0 0 00
Color 2 19 8 13
Color 3 39 15 27
Color 4 58 23 3A
Color 5 78 31 4E
Color 6 98 38 62
Color 7 117 46 75
Color 8 137 54 89
Color 9 156 61 9C
Color 10 176 69 B0
Color 11 196 77 C4
Color 12 215 84 D7
Color 13 235 92 EB
Color 1 (open) 255 100 FF
Scan Mode - two colors
Color 1 and 2 0-23 0-8 00-17
Color 2 and 3 24-31 9-12 18-1F
Color 3 and 4 32-39 13-15 20-27
Color 4 and 5 40-47 16-18 28-2F
Color 5 and 6 48-55 19-21 30-37
Color 6 and 7 56-63 22-25 38-3F
Color 7 and 8 64-71 26-28 40-47
Color 8 and 9 72-79 29-31 48-4F
Color 9 and 10 80-87 32-34 50-57
Color 10 and 11 88-95 35-37 58-5F
Color 11 and 12 96-103 38-40 60-67
Color 12 and 13 104-111 41-44 68-6F
Color 13 and 1 112-127 45-50 70-7F
Scan Mode - three colors
Color 13 and 1 and 2 128-151 51-59 80-97
Color 1 and 2 and 3 152-159 60-62 98-9F
Color 2 and 3 and 4 160-167 63-66 A0-A7
Color 3 and 4 and 5 168-175 67-69 A8-AF
Color 4 and 5 and 6 176-183 70-72 B0-B7
Color 5 and 6 and 7 184-191 73-75 B8-BF
Color 6 and 7 and 8 192-199 76-78 C0-C7
Table A-2. Technobeam-i DMX Protocol
Ch. Construct Parameter
Value
(dec.)
Value
(%)
Value
(hex)
