Technobeam
®
User Manual Optional Accessories 1-5
Environmental Specifications
Maximum ambient temperature (T
a
): 50° C (122° F)
Maximum exterior surface temperature: 70° C (158° F)
Minimum distance to flammable objects: 1.0 m (3.28 ft)
Minimum distance to lighted object: 1.0 m (3.28 ft)
DMX Data Cabling
•
DMX data cables:
Belden
®
9841 or equivalent (meets
specifications for EIA RS-485 applications) with characteristics
listed below:
• 2-conductor, twisted pair plus a shield
• maximum capacitance between conductors - 30 pF/ft.
• maximum capacitance between conductor & shield - 55 pF/ft.
• maximum resistance of 20
Ω
/1000 ft.
• nominal impedance 100–140
Ω
• 22–24 AWG with insulation having a dielectric rating of 300
volts or higher
•
DMX data connectors:
3-pin male and female XLR connectors
•
DMX data terminators:
Male XLR connector with 120 ohm
terminator between pins 2 and 3 (see Figure 2-4 on page 2-6)
Controllers
Technobeam may be controlled with any of the following:
•The Status Cue
®
lighting system
• The Technobeam LCD controller
• Another DMX 512-compatible controller
Optional Accessories
Table 1-1 below shows the optional accessories for Technobeam,
available from your High End Systems
®
dealer/distributor:
Table 1-1. Optional Accessories
Name Part Number
Optional lens sets Call*
Replacement MSD 250-2 lamp Call*
Custom color wheel dichroic filters Call*
LithoPatterns Call*
