A-6 DMX Protocols Technobeam
®
User Manual
Random Random pause time,
shortest to longest
0 - 255 0 - 100 00h - FFh
Scan Scan rate, slowest to
fastest
0 - 255 0 - 100 00h - FFh
Litho wheel spin (use with ch. 7
(F) or ch. 5 (R)
Entire wheel spins, not
individual lithos
Forward spin, fastest to
slowest
0 - 119 0 - 47 0 - 77h
No spin 120 - 135 47 - 53 78h - 87h
Reverse spin, slowest
to fastest
136 - 255 53 - 100 88h - FFh
10 n/a
Litho rotation (fine
adjustment)
Angular position for
blink and index modes
0 - 255 0 - 100 00h - FFh
11 8
Effects position
Fast effects changes (at
beginning of wheel movement)
Select the position with this
channel. Then use ch. 12 (F) or
ch. 9 (R) to set spin direction
and speed.
Position 1 0 - 25 0 - 9 00h - 19h
Position 2 26 - 51 10 - 20 1Ah - 33h
Position 3 52 - 76 21 - 29 34h - 4Ch
Position 4 77 - 102 31 - 40 4Dh - 66h
Position 5 103 - 127 41 - 49 67h - 7Fh
Effects changes set by MSpeed
(use ch. 16 (F) or 13 (R) to set
MSpeed time)
Select the position with this
channel. Then use ch. 12 (F) or
ch. 9 (R) to set spin direction
and speed
Position 1 128 - 153 50 - 60 80h - 99h
Position 2 154 - 178 61 - 69 9Ah - B2h
Position 3 179 - 204 70 - 80 B2h - CCh
Position 4 205 - 229 81 - 89 CDh - E5h
Position 5 230 - 255 90 - 100 E6h - FFh
12 9
Effects spin speed
(use with ch. 11 (F) or
ch. 8 (R))
Forward spin fast to
slow forward spin
0 - 120 0 - 47 00h - 78h
No spin 121 - 134 48 - 52 79h - 86h
Reverse spin slow to
fast forward spin
135 - 255 53 - 100 87h - FFh
13 10
Focus
Variable focus 0 - 255 0 - 100 00h - FFh
14 11
Shutter
Longest ramp time = lowest
value (snap time is always
short)
Closed 0 - 7 0 - 2 00h - 07h
Periodic strobe 8 - 67 3 - 26 08h - 43h
Random strobe 68 - 127 27 - 49 44h - 7Fh
Ramp open, snap shut 128 - 187 50 - 73 80h - BBh
Snap open, ramp shut 188 - 247 74 - 96 BCh - F7h
Open 248 - 255 97 - 100 F8h - FFh
15 12
Dim
Full dark to full bright 0 - 255 0 - 100 00h - FFh
16 13
MSpeed
Movement time (see Table A-3 on page A-13)
Table A-1. Technobeam DMX Protocol
Ch. (F) Ch. (R) Construct Parameter
Value
(dec.)
Value
(%)
Value
(hex)
